MLA - 85
Ref.: AMMI285
1/2 wave
1,1/1 adjustable
+ 3 dBi
250 Watt P.E.P
550 kHz (55 cx)
1,150 kg
930 mm
Magnetic
AC4 Stainless steel
Specifications
| Antenna type | : | 1/2 wave |
| Impedance | : | 50 Ohms |
| Frequency | : | 26-28 MHz |
| Polarization | : | Vertical |
| S.W.R. value | : | 1,1/1 adjustable |
| Gain | : | + 3 dBi |
| Maximum power | : | 250 Watt P.E.P |
| Band width / Number of channels | : | 550 kHz (55 cx) |
| Weight | : | 1,150 kg |
| Length | : | 930 mm |
| Base type | : | Magnetic |
| Reclining | : | |
| Dismantled magnetic base | : | |
| Whip | : | AC4 Stainless steel |
